Ultrasonic Welding Machine 20K 2000W For Composite Materials, Films and Paper Continuous Bonding
Description:
Ultrasonic non-woven welding machine is an efficient sewing and embossing equipment. It is mainly used for seaming, welding, fusion cutting and embossing of synthetic fiber fabrics. The processed products have good water tightness, high production efficiency, no need for needle thread accessories, smooth cut surface without burr and good hand feeling. Widely used in clothing, toys, food, environmentally friendly non-woven bags, masks and other industries.
Specification:
| Frequency | 20Khz |
| Power | 2000 watt |
| Voltage | AC110-240V, 50/60Hz |
| Power Control | stepping or continuous |
| Material of welding head | aluminum alloy, stainless steel, titanium alloy, alloy steel. |
| Weight | 4 kg- 20KG |
| Generator | Analog |
| Cooling device | compressed air mouth can be installed. |
| Cable length | or customized |
| Max. sewing speed | 0-20m/min, 20 M/min, Customize, 450spm, 10m/5seconds |
Competitive Advantage:
1. Ultrasonic welding eliminates the need for needle threading, eliminating the need for frequent needle changing. Without the traditional broken wire joints, it can also clean and partially cut and seal textiles.
2, The stitching also plays the role of decoration, strong adhesion, can achieve waterproof effect, clear embossing, the surface has a three-dimensional relief effect, work speed, product effect is more high-end aesthetic, quality is guaranteed.
3, Using ultrasonic and special steel wheel processing, the edge of the seal does not crack, does not hurt the edge of the cloth, and there is no flashing, curling phenomenon.
4. It does not need to be preheated during manufacturing and can be operated continuously.
5, The operation is simple, and the traditional sewing machine operation method is not much different, ordinary sewing workers can operate
6, Low cost, 5 to 6 times faster than traditional machines, high efficiency.
Applications:
Chemical synthetic fiber fabrics, or chemical fiber blended fabrics, chemical films are also containing more than 30% of the weaving, can be processed into the desired products, such as Nylon cloth, knitted fabrics, non-woven fabrics, T / R cloth, Tedron Cloth (Polyester cloth), glitter cloth, multi-layer cloth, and various laminated coated paper-coated film papers are applicable.
Why Altrasonic?
G After-sale service:
1. 1. 24 hours techician hotline
2. 2. Preventative maintenance and servicing measures.
3. Reworking of tooling and spart parts management.
4. Targeted production process optimization.
Start up:
1 1. On-site intergration and start-up of the ultrasonic welding syetems by our service specialists.
2. Ensuring a smooth and fast production start up.
3. Fine-tuning and optimization of the bonding processing quality.
